The New Professional Class – Brilliant Optics in a Noble Design
The PX-30E is the highest quality document camera from ELMO. It was designed primarily for use in meeting rooms and lecture halls with upscale amenities.
The 4K camera is state-of-the-art and delivers a razor-sharp image at up to 60 frames per second. The high zoom factor makes even the smallest details visible. The combination of optical, digital and sensor zoom allows a total of 288x magnification.
The usual intuitive operation ensures relaxed and flexible presentation. The PX-30E is easily controlled via the control panel with integrated touch display. In addition to the menu navigation, the live image is always available here as well. The wipeable writing surface provides space for handwritten notes without paper.
Numerous connections allow uncomplicated integration in new as well as existing installations. Externally, the PX-30E can be controlled via network (TCP / IP Control) or RS232-C.
Highest Quality Image
With the 4K camera and excellent zoom (12x optical, 2x sensor, 12x digital), the PX-30E delivers crisp, clear images on all modern screens and projectors.
All controls are located on the front edge of the PX-30E and are always easy to reach. Thanks to the preview display with touch function you always have the presentation in view. The scope of delivery also includes a remote control.
The PX-30E has many options. The image can be reproduced via HDMI, HDBaseT and VGA. Via USB 3.0, the live image can be transferred to a computer. External control is possible via network (TCP / IP Control) and RS232-C.
For easy switching between different external image sources, the PX-30E has two HDMI and one VGA input.
An LED light is integrated in the arm of the PX-30E. This ensures ideal illumination and is positioned in a way that reflections on smooth surfaces are kept to a minimum.
Save Photos and Videos
Everything shown can be recorded and played back as a photo (JPEG) or video (mp4) on an SD card, USB stick or the internal memory by pressing a button.
- 4K-camera and 12-megapixel CMOS-sensor
- Impressive magnification through combination of optical, sensor and digital zoom
- Image replication via HDMI, HDBaseT, VGA or USB
- Unobtrusively integrated LED light for optimal illumination with low reflection
- Preview display with touch function
- Intuitive control through clear menu navigation
- Wipeable, magnetic writing surface
